| Items | Value | |
|---|---|---|
| Product Specification | Dimension | 460 x 220 x 70 (mm) |
| Materials | Aluminum | |
| Max. PLC Axis | 6 | |
| Standard Axis | 6 | |
| Max. Axis (Optional) | 6 | |
| Max. Spindle | 2 | |
| Max Spindle Simultaneous Axis Control | 6 | |
| Min. Control Unit | 0.0001 | |
| Max. Number Of Program Coordinate | 18 | |
| Max. Number of Table Tools | 40 | |
| Look-Ahead | 1000 | |
| Block Processing Time | 1000 | |
| Hardware | Standard I/O | 24/16 |
| Optional I/O | 256/256 | |
| DA | 2 | |
| Monitor | 10.4 Inch | |
| RS485 | 1 | |
| USB Port | 1 | |
| Compensation | Backlash Compensation | Yes |
| Pitch Error Compensation | Yes | |
| Functions | MPG Simulation | Yes |
| Dry Run | Yes | |
| Optional Stop | Yes | |
| Single Block | Yes | |
| External Offsets | Yes | |
| MPG Offsets | Yes |
Recognized as the leading entity in Vietnam, developing, applying, and trading CNC control products. After several years of product development, our products have been widely applied in the industry, and we have gained trust and attention from both domestic and international customers.
